Wireless Presure Switch Internal Sliding Doors Systems Light Gray Surface

Name: Wireless Presure Switch Internal Sliding Doors Systems Light Gray Surface
Brand: Caterly
Price: 200.00 USD

Buy cheap Wireless Presure Switch Internal Sliding Doors Systems Light Gray Surface product

Brand Name : Caterly

Model Number : D-H

Certification : CE,ISO9001:2008

Place of Origin : Guangdong , China

MOQ : 5 sets

Price : USD200.00/set to USD 450 .00/set

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 3,000 Sets per Month

Delivery Time : 3-7 work days

Packaging Details : foam and cardboard cartons and wooden pallet

power : 25W

Input voltage : 110V to 240V

Opening speed : 15mm/s to 45mm/s

closing speed : 15mm/s to 45mm/s

door weight : 20KG to 60KG ( Double leaf)

Contact Now

Wireless presure switch Sliding Door , light gray surface Residential Automatic Sliding Doors

Specifications:
1. Center Building Automatic Door
2. Access Control Accessories
3. Germany Technology
4. Aluminum Rail 4.2m
5. CE Certification

Reliability,

a) Imported Microchips MCU to control the door working. 24V,60W, DC bruthless motor have big power to hold 150kg panels, work a long time and noise is 50db to 60db.
b) With the help of advanced synchronous belt and perfect design of power supply circuit , the door moves very stably.
c) Panasonic track and anti-derail rubber on the hanger roller to protect from derailing. Our this techniques is veyr mature. and can promise it can't derail.

Packaging & Delivery

Packaging Details:	Foam inside, Waterproof colorful Carton outside, Euro Pallet
Delivery Detail:	Stock all the time

Door Operator Specification,

Door model	Single	Bi-Parting
Door width	600-1300mm	600mm-1250mmn
Door weight	60kg	30kg x 2
Opening speed	15cm-50cm/s	15cm-45cm/s
Closing speed	10cm-45cm/s	10cm-43cm/s
Hold on time:	0-9s
Motor	brushless 24 volt DC,60W ,high torque 3000r/min
Microcontroller	PLC techniques and 8 bit chip, Visialbe adjustment screen
Power supply	110V-240V,60Hz/50Hz
Profile size	4200mm(L)x 128mm(H)x 100mm(W)

Retro-fit kit
1	Motor & Gearbox	1pcs	China-made 24V,25W ,DC bruthless motor
2	Microcontroller	1pc	8 bit Microchip chip
3	Radar	2pcs	bea microwave sensor
4	Learning code remote controller	1set	Hold-open,lock,exit only, half-open,automatic
5	Carriage	4pcs	2 running wheel
6	Tooth belt	1pc	8m, fiberglass tensile elements, nylon surface
7	Belt clamp	2pcs
8	Idle pulley	1pc	Aluminum alloy
9	Stopper	2pcs	Aluminum alloy
10	Connection termial	1pc	For 220V power ,and outside sensor connection
Profile
1	Track	1pc	3mm thickenss, Anodize, height 125mm, depth 100mm,length 4200mm
2	Cover	1pc	170mm height,anodized
Options
1	Photocell	1set	factory,made
2	Electro-mechanical lock	1set	12V,time delay
3	Emergency battery	1set	12V,7Ah,contiunously working half an hours
4	Control panels	1set	LCD display, key swtich,5 program adjust
5	Floor guide	2pcs	For frame and frameless door
6	Glass clamp	2pcs	1m length, fit to 10mm,12mm glass

Wireless Presure Switch Internal Sliding Doors Systems Light Gray Surface

Product Tags:

electronic sliding doors

indoor sliding doors

Wireless Presure Switch Internal Sliding Doors Systems Light Gray Surface Images
